100W MONOCYSTALIINE SOLAR PANEL
| Feature | Specification |
|---|---|
| Panel Type | Monocrystalline |
| Maximum Power (Pmax) | 100 Watts |
| Operating Voltage (Vmp) | 18V – 20V (commonly around 18.0V) |
| Operating Current (Imp) | 5.5A – 5.8A |
| Open Circuit Voltage (Voc) | 21V – 22.5V |
| Short Circuit Current (Isc) | 5.8A – 6.2A |
| Module Efficiency | 17% – 21% |
| Cell Type | A-grade Monocrystalline Silicon Cells |
| Number of Cells | 36 cells (typically 4 x 9 layout) |
| Dimensions | Approx. 1000mm x 670mm x 30mm (L x W x H) |
| Weight | Approx. 6 – 8 kg |
| Frame Material | Anodized aluminum alloy |
| Glass | High-transparency tempered glass (3.2mm) |
| Junction Box | IP65/IP67 rated, with bypass diodes |
| Cable & Connectors | 90cm solar cables with MC4 connectors |
| Operating Temperature | -40°C to +85°C |
| Maximum System Voltage | 1000V DC (IEC) or 600V DC (UL) |
| Warranty | 10–25 years (performance warranty depending on brand) |
| Usage | Off-grid systems, lighting kits, solar water pumps, camping, etc. |
